abstract codec class for JPEG encoders. More...
Public Member Functions | |
DJCodecEncoder () | |
default constructor | |
virtual | ~DJCodecEncoder () |
destructor | |
virtual OFCondition | decode (const DcmRepresentationParameter *fromRepParam, DcmPixelSequence *pixSeq, DcmPolymorphOBOW &uncompressedPixelData, const DcmCodecParameter *cp, const DcmStack &objStack, OFBool &removeOldRep) const |
decompresses the given pixel sequence and stores the result in the given uncompressedPixelData element. More... | |
virtual OFCondition | decodeFrame (const DcmRepresentationParameter *fromParam, DcmPixelSequence *fromPixSeq, const DcmCodecParameter *cp, DcmItem *dataset, Uint32 frameNo, Uint32 &startFragment, void *buffer, Uint32 bufSize, OFString &decompressedColorModel) const |
decompresses a single frame from the given pixel sequence and stores the result in the given buffer. More... | |
virtual OFCondition | encode (const Uint16 *pixelData, const Uint32 length, const DcmRepresentationParameter *toRepParam, DcmPixelSequence *&pixSeq, const DcmCodecParameter *cp, DcmStack &objStack, OFBool &removeOldRep) const |
compresses the given uncompressed DICOM image and stores the result in the given pixSeq element. More... | |
virtual OFCondition | encode (const E_TransferSyntax fromRepType, const DcmRepresentationParameter *fromRepParam, DcmPixelSequence *fromPixSeq, const DcmRepresentationParameter *toRepParam, DcmPixelSequence *&toPixSeq, const DcmCodecParameter *cp, DcmStack &objStack, OFBool &removeOldRep) const |
transcodes (re-compresses) the given compressed DICOM image and stores the result in the given toPixSeq element. More... | |
virtual OFBool | canChangeCoding (const E_TransferSyntax oldRepType, const E_TransferSyntax newRepType) const |
checks if this codec is able to convert from the given current transfer syntax to the given new transfer syntax More... | |
virtual OFCondition | determineDecompressedColorModel (const DcmRepresentationParameter *fromParam, DcmPixelSequence *fromPixSeq, const DcmCodecParameter *cp, DcmItem *dataset, OFString &decompressedColorModel) const |
determine color model of the decompressed image More... | |
virtual E_TransferSyntax | supportedTransferSyntax () const =0 |
returns the transfer syntax that this particular codec is able to encode and decode. More... | |
Public Member Functions inherited from DcmCodec | |
DcmCodec () | |
default constructor | |
virtual | ~DcmCodec () |
destructor | |
virtual OFCondition | decode (const DcmRepresentationParameter *fromRepParam, DcmPixelSequence *pixSeq, DcmPolymorphOBOW &uncompressedPixelData, const DcmCodecParameter *cp, const DcmStack &objStack, OFBool &removeOldRep) const =0 |
decompresses the given pixel sequence and stores the result in the given uncompressedPixelData element. More... | |
virtual OFCondition | decodeFrame (const DcmRepresentationParameter *fromParam, DcmPixelSequence *fromPixSeq, const DcmCodecParameter *cp, DcmItem *dataset, Uint32 frameNo, Uint32 &startFragment, void *buffer, Uint32 bufSize, OFString &decompressedColorModel) const =0 |
decompresses a single frame from the given pixel sequence and stores the result in the given buffer. More... | |
virtual OFCondition | encode (const Uint16 *pixelData, const Uint32 length, const DcmRepresentationParameter *toRepParam, DcmPixelSequence *&pixSeq, const DcmCodecParameter *cp, DcmStack &objStack, OFBool &removeOldRep) const =0 |
compresses the given uncompressed DICOM image and stores the result in the given pixSeq element. More... | |
virtual OFCondition | encode (const E_TransferSyntax fromRepType, const DcmRepresentationParameter *fromRepParam, DcmPixelSequence *fromPixSeq, const DcmRepresentationParameter *toRepParam, DcmPixelSequence *&toPixSeq, const DcmCodecParameter *cp, DcmStack &objStack, OFBool &removeOldRep) const =0 |
transcodes (re-compresses) the given compressed DICOM image and stores the result in the given toPixSeq element. More... | |
virtual OFBool | canChangeCoding (const E_TransferSyntax oldRepType, const E_TransferSyntax newRepType) const =0 |
checks if this codec is able to convert from the given current transfer syntax to the given new transfer syntax More... | |
virtual OFCondition | determineDecompressedColorModel (const DcmRepresentationParameter *fromParam, DcmPixelSequence *fromPixSeq, const DcmCodecParameter *cp, DcmItem *dataset, OFString &decompressedColorModel) const =0 |
determine color model of the decompressed image More... | |
Static Protected Member Functions | |
static void | appendCompressionRatio (OFString &arg, double ratio) |
format compression ratio as string and append to given string object. More... | |
static OFCondition | togglePlanarConfiguration8 (Uint8 *pixelData, const size_t numValues, const Uint16 samplesPerPixel, const Uint16 oldPlanarConfig) |
toggles Planar Configuration of 8-bit pixel data from "by pixel" to "by plane" and vice versa. More... | |
static OFCondition | togglePlanarConfiguration16 (Uint16 *pixelData, const size_t numValues, const Uint16 samplesPerPixel, const Uint16 oldPlanarConfig) |
toggles Planar Configuration of 16-bit pixel data from "by pixel" to "by plane" and vice versa. More... | |
Private Member Functions | |
virtual OFCondition | encodeColorImage (OFBool YBRmode, DcmItem *dataset, const DcmRepresentationParameter *toRepParam, DcmPixelSequence *&pixSeq, const DJCodecParameter *cp, double &compressionRatio) const |
compresses the given uncompressed DICOM color image and stores the result in the given pixSeq element. More... | |
virtual OFCondition | encodeMonochromeImage (DcmItem *dataset, const DcmRepresentationParameter *toRepParam, DcmPixelSequence *&pixSeq, const DJCodecParameter *cp, double &compressionRatio) const |
compresses the given uncompressed monochrome DICOM image and stores the result in the given pixSeq element. More... | |
virtual OFCondition | encodeTrueLossless (const DcmRepresentationParameter *toRepParam, DcmPixelSequence *&pixSeq, const DcmCodecParameter *cp, DcmStack &objStack) const |
compresses the given uncompressed DICOM image and stores the result in the given pixSeq element. More... | |
virtual OFCondition | updateLossyCompressionRatio (DcmItem *dataset, double ratio) const |
create Lossy Image Compression and Lossy Image Compression Ratio. More... | |
virtual OFCondition | updateDerivationDescription (DcmItem *dataset, const DcmRepresentationParameter *toRepParam, const DJCodecParameter *cp, Uint8 bitsPerSample, double ratio) const |
create Derivation Description. More... | |
virtual OFCondition | adjustOverlays (DcmItem *dataset, DicomImage &image) const |
for all overlay groups create (60xx,3000) Overlay Data. More... | |
virtual OFBool | isLosslessProcess () const =0 |
returns true if the transfer syntax supported by this codec is lossless. More... | |
virtual void | createDerivationDescription (const DcmRepresentationParameter *toRepParam, const DJCodecParameter *cp, Uint8 bitsPerSample, double ratio, OFString &derivationDescription) const =0 |
creates 'derivation description' string after encoding. More... | |
virtual DJEncoder * | createEncoderInstance (const DcmRepresentationParameter *toRepParam, const DJCodecParameter *cp, Uint8 bitsPerSample) const =0 |
creates an instance of the compression library to be used for encoding/decoding. More... | |
Static Private Member Functions | |
static OFCondition | correctVOIWindows (DcmItem *dataset, double voiOffset, double voiFactor) |
modifies all VOI window center/width settings in the image. More... | |
Additional Inherited Members | |
Static Public Member Functions inherited from DcmCodec | |
static OFCondition | insertStringIfMissing (DcmItem *dataset, const DcmTagKey &tag, const char *val) |
helper function that inserts a string attribute with a given value into a dataset if missing in the dataset. More... | |
static OFCondition | convertToSecondaryCapture (DcmItem *dataset) |
helper function that converts a dataset containing a DICOM image into a valid (standard extended) Secondary Capture object by inserting all attributes that are type 1/2 in Secondary Capture and missing in the source dataset. More... | |
static OFCondition | newInstance (DcmItem *dataset, const char *purposeOfReferenceCodingScheme=NULL, const char *purposeOfReferenceCodeValue=NULL, const char *purposeOfReferenceCodeMeaning=NULL) |
create new SOP instance UID and Source Image Sequence referencing the old SOP instance (if present) More... | |
static OFCondition | updateImageType (DcmItem *dataset) |
set first value of Image Type to DERIVED. More... | |
static OFCondition | insertCodeSequence (DcmItem *dataset, const DcmTagKey &tagKey, const char *codingSchemeDesignator, const char *codeValue, const char *codeMeaning) |
insert code sequence into the given dataset More... | |
static OFCondition | determineStartFragment (Uint32 frameNo, Sint32 numberOfFrames, DcmPixelSequence *fromPixSeq, Uint32 ¤tItem) |
determine the index number (starting with zero) of the compressed pixel data fragment corresponding to the given frame (also starting with zero) More... | |
abstract codec class for JPEG encoders.
This abstract class contains most of the application logic needed for a dcmdata codec object that implements a JPEG encoder using the DJEncoder interface to the underlying JPEG implementation. This class only supports compression, it neither implements decoding nor transcoding.
|
privatevirtual |
for all overlay groups create (60xx,3000) Overlay Data.
dataset | dataset to be modified |
image | DicomImage object for this dataset |
|
staticprotected |
format compression ratio as string and append to given string object.
arg | string to append to |
ratio | compression ratio |
|
virtual |
checks if this codec is able to convert from the given current transfer syntax to the given new transfer syntax
oldRepType | current transfer syntax |
newRepType | desired new transfer syntax |
Implements DcmCodec.
|
staticprivate |
modifies all VOI window center/width settings in the image.
Modifications are based on the pixel value mapping f(x) = (x+voiOffset)*voiFactor
dataset | dataset to be updated |
voiOffset | offset to be added to each pixel |
voiFactor | factor to be multiplied |
|
privatepure virtual |
creates 'derivation description' string after encoding.
toRepParam | representation parameter passed to encode() |
cp | codec parameter passed to encode() |
bitsPerSample | bits per sample of the original image data prior to compression |
ratio | image compression ratio. This is not the "quality factor" but the real effective ratio between compressed and uncompressed image, i. e. 30 means a 30:1 lossy compression. |
derivationDescription | derivation description returned in this parameter which is initially empty |
Implemented in DJEncoderBaseline, DJEncoderExtended, DJEncoderLossless, DJEncoderProgressive, DJEncoderSpectralSelection, and DJEncoderP14SV1.
|
privatepure virtual |
creates an instance of the compression library to be used for encoding/decoding.
toRepParam | representation parameter passed to encode() |
cp | codec parameter passed to encode() |
bitsPerSample | bits per sample for the image data |
Implemented in DJEncoderBaseline, DJEncoderExtended, DJEncoderLossless, DJEncoderProgressive, DJEncoderSpectralSelection, and DJEncoderP14SV1.
|
virtual |
decompresses the given pixel sequence and stores the result in the given uncompressedPixelData element.
fromRepParam | current representation parameter of compressed data, may be NULL |
pixSeq | compressed pixel sequence |
uncompressedPixelData | uncompressed pixel data stored in this element |
cp | codec parameters for this codec |
objStack | stack pointing to the location of the pixel data element in the current dataset. |
removeOldRep | boolean flag that should be set to false before this method call and will be set to true if the codec modifies the DICOM dataset such that the pixel data of the original representation may not be usable anymore. |
Implements DcmCodec.
|
virtual |
decompresses a single frame from the given pixel sequence and stores the result in the given buffer.
fromParam | representation parameter of current compressed representation, may be NULL. |
fromPixSeq | compressed pixel sequence |
cp | codec parameters for this codec |
dataset | pointer to dataset in which pixel data element is contained |
frameNo | number of frame, starting with 0 for the first frame |
startFragment | index of the compressed fragment that contains all or the first part of the compressed bitstream for the given frameNo. Upon successful return this parameter is updated to contain the index of the first compressed fragment of the next frame. When unknown, zero should be passed. In this case the decompression algorithm will try to determine the index by itself, which will always work if frames are decompressed in increasing order from first to last, but may fail if frames are decompressed in random order, multiple fragments per frame and multiple frames are present in the dataset, and the offset table is empty. |
buffer | pointer to buffer where frame is to be stored |
bufSize | size of buffer in bytes |
decompressedColorModel | upon successful return, the color model of the decompressed image (which may be different from the one used in the compressed images) is returned in this parameter. |
Implements DcmCodec.
|
virtual |
determine color model of the decompressed image
fromParam | representation parameter of current compressed representation, may be NULL |
fromPixSeq | compressed pixel sequence |
cp | codec parameters for this codec |
dataset | pointer to dataset in which pixel data element is contained |
dataset | pointer to DICOM dataset in which this pixel data object is located. Used to access photometric interpretation. |
decompressedColorModel | upon successful return, the color model of the decompressed image (which may be different from the one used in the compressed images) is returned in this parameter |
Implements DcmCodec.
|
virtual |
transcodes (re-compresses) the given compressed DICOM image and stores the result in the given toPixSeq element.
fromRepType | current transfer syntax of the compressed image |
fromRepParam | current representation parameter of compressed data, may be NULL |
fromPixSeq | compressed pixel sequence |
toRepParam | representation parameter describing the desired new compressed representation (e.g. JPEG quality) |
toPixSeq | compressed pixel sequence (pointer to new DcmPixelSequence object allocated on heap) returned in this parameter upon success. |
cp | codec parameters for this codec |
objStack | stack pointing to the location of the pixel data element in the current dataset. |
removeOldRep | boolean flag that should be set to false before this method call and will be set to true if the codec modifies the DICOM dataset such that the pixel data of the original representation may not be usable anymore. |
Implements DcmCodec.
|
virtual |
compresses the given uncompressed DICOM image and stores the result in the given pixSeq element.
pixelData | pointer to the uncompressed image data in OW format and local byte order |
length | of the pixel data field in bytes |
toRepParam | representation parameter describing the desired compressed representation (e.g. JPEG quality) |
pixSeq | compressed pixel sequence (pointer to new DcmPixelSequence object allocated on heap) returned in this parameter upon success. |
cp | codec parameters for this codec |
objStack | stack pointing to the location of the pixel data element in the current dataset. |
removeOldRep | boolean flag that should be set to false before this method call and will be set to true if the codec modifies the DICOM dataset such that the pixel data of the original representation may not be usable anymore. |
Implements DcmCodec.
|
privatevirtual |
compresses the given uncompressed DICOM color image and stores the result in the given pixSeq element.
YBRmode | true if the source image has YBR_FULL or YBR_FULL_422 photometric interpretation and can thus be compressed without color space conversion. |
dataset | DICOM dataset containing the pixel data as well as descriptive attributes |
toRepParam | representation parameter describing the desired compressed representation (e.g. JPEG quality) |
pixSeq | compressed pixel sequence (pointer to new DcmPixelSequence object allocated on heap) returned in this parameter upon success. |
cp | codec parameters for this codec |
compressionRatio | compression ratio returned in this parameter if successful. |
|
privatevirtual |
compresses the given uncompressed monochrome DICOM image and stores the result in the given pixSeq element.
dataset | DICOM dataset containing the pixel data as well as descriptive attributes |
toRepParam | representation parameter describing the desired compressed representation (e.g. JPEG quality) |
pixSeq | compressed pixel sequence (pointer to new DcmPixelSequence object allocated on heap) returned in this parameter upon success. |
cp | codec parameters for this codec |
compressionRatio | compression ratio returned in this parameter if successful. |
|
privatevirtual |
compresses the given uncompressed DICOM image and stores the result in the given pixSeq element.
No colorspace conversions, modality or windowing transformations are applied to guarantee, that the quality of the source image is fully preserved.
toRepParam | - [in] representation parameter describing the desired |
pixSeq | - [out] compressed pixel sequence (pointer to new DcmPixelSequence object allocated on heap) returned in this parameter upon success |
cp | - [in] codec parameters for this codec |
objStack | - [in/out] stack pointing to the location of the pixel data element in the current dataset. |
|
privatepure virtual |
returns true if the transfer syntax supported by this codec is lossless.
Implemented in DJEncoderBaseline, DJEncoderExtended, DJEncoderLossless, DJEncoderProgressive, DJEncoderSpectralSelection, and DJEncoderP14SV1.
|
pure virtual |
returns the transfer syntax that this particular codec is able to encode and decode.
Implemented in DJEncoderBaseline, DJEncoderExtended, DJEncoderLossless, DJEncoderProgressive, DJEncoderSpectralSelection, and DJEncoderP14SV1.
|
staticprotected |
toggles Planar Configuration of 16-bit pixel data from "by pixel" to "by plane" and vice versa.
pixelData | - [in/out] Original pixel data (input), contains pixel data with toggled Planar configuration after returning (output). |
numValues | - [in] The number of 16 bit values in pixelData |
samplesPerPixel | - [in] Number of components for one pixel |
oldPlanarConfig | - [in] The old Planar Configuration, that should be toggled. 0 means "by pixel", 1 "by color" |
|
staticprotected |
toggles Planar Configuration of 8-bit pixel data from "by pixel" to "by plane" and vice versa.
pixelData | - [in/out] Original pixel data (input), contains pixel data with toggled Planar configuration after returning (output). |
numValues | - [in] The number of 8 bit values in pixelData |
samplesPerPixel | - [in] Number of components for one pixel |
oldPlanarConfig | - [in] The old Planar Configuration, that should be toggled. 0 means "by pixel", 1 "by color" |
|
privatevirtual |
create Derivation Description.
dataset | dataset to be modified |
toRepParam | representation parameter passed to encode() |
cp | codec parameter passed to encode() |
bitsPerSample | bits per sample of the original image data prior to compression |
ratio | image compression ratio. This is not the "quality factor" but the real effective ratio between compressed and uncompressed image, i. e. 30 means a 30:1 lossy compression. |
|
privatevirtual |
create Lossy Image Compression and Lossy Image Compression Ratio.
dataset | dataset to be modified |
ratio | image compression ratio > 1. This is not the "quality factor" but the real effective ratio between compressed and uncompressed image, i. e. 30 means a 30:1 lossy compression. |
